I. Introduction
Author: Beijing Guojie Pipeline Co., Ltd.
In engineering construction fields such as chemical, oil and gas, heating, municipal water supply and drainage, and power stations, pipeline fittings, as core pressure-bearing components of pressure piping systems, include products such as elbows, tees, reducers, flanges, pipe caps, and blind plates, and their procurement quality directly determines the operational safety of the entire pressure piping system.Pressure piping fittings are classified within the scope of special equipment management, and procurement work differs from ordinary general material procurement. It must take into account special requirements such as technical standards, material compliance, heat number traceability, inspection and testing, and quality certification documents. Once control over the procurement process is lacking, it is very easy for specification mismatches, material nonconformity, incomplete documentation, and blocked acceptance to occur, and even to cause project shutdown and rework, resulting in huge economic losses.
Regular orders are the highest-proportion business type in pipeline fitting procurement, distinct from emergency repair orders, long-cycle orders for large general contracting projects, and special orders for non-standard customization.Regular orders generally refer to pipeline fitting procurement tasks with clear requirements, complete drawings, implementation of national standards or the general American standard ASME specifications, stable batch sizes, and controllable delivery cycles.At present, many project procurement personnel simplify fitting procurement into price comparison and order placement, emphasizing price over technical review and emphasizing arrival over in-process supervision, lacking a standardized closed-loop procurement process, which causes quality disputes in the later stages of the project.
Procurement of regular orders for pipeline fittings is a complete closed-loop management system. Starting from the engineering discipline raising material requirements, it proceeds in sequence through procurement requirement review, technical clarification, supplier admission evaluation, preparation of inquiry documents, collection of supplier quotations, technical and commercial review, signing of contracts and technical agreements, production scheduling, in-process supervision, factory inspection, packaging and shipment, on-site arrival acceptance, document verification, warehousing and storage, settlement and payment, and finally completion of document archiving and supplier performance evaluation.Technical reviews and risk control points are set at every stage to ensure that the delivered pipe fittings meet the requirements of drawings, standards, and special equipment safety regulations.This article systematically breaks down the entire conventional order procurement process, clarifies the work content, review priorities, common risks, and control measures at each stage, and builds an implementable standard operating procedure for conventional procurement of piping fittings, providing theoretical and practical reference for procurement practitioners.
II. Procurement demand submission and demand review stage
The procurement process starts with the engineering design or construction discipline submitting a material requisition, including the material take-off (MTO), piping isometric drawings, P&ID drawings, fitting list, and technical data sheets, forming a purchase requisition (PR).The purchase requisition documents must fully specify key information such as fitting name, specification and size, nominal pressure/pound rating, wall thickness schedule (SCH), material grade, governing standard, quantity, delivery location, latest arrival time, inspection certificate requirements, and special test items.Piping fittings have numerous parameters, and the absence of any single parameter will cause subsequent quotation deviations and supply errors.
The preliminary demand review is divided into a procurement discipline preliminary review and a technical discipline re-review.Procurement personnel check the completeness of the requisition documents, verify the quantities in the list, and identify missing items;Pipeline technical engineers review drawings and technical parameters, confirm pressure ratings, materials, and standard compatibility, distinguish GC pressure piping classes, and determine whether special equipment manufacturing licenses, third-party supervision inspections, and non-destructive testing (NDT) are required.At this stage, the focus is on identifying contradictions in drawing parameters and issues of mixed standards, such as mixing American standard ASME pound classes with national standard PN, incorrect selection of wall thickness grades, and non-standard material grade designations.
Common issues in the requirements review stage: inconsistencies between the single-line diagram and the material list quantities, missing requirements for gaskets matched with flanges, failure to specify whether certificates are EN10204 3.1 or 3.2 versions, and missing requirements for heat treatment and PMI spectral inspection.If there are deficiencies in the requirement documents, the procurement department returns them to the requesting discipline for supplementation and improvement; incomplete documents must not proceed to the inquiry stage.After requirement confirmation is completed, technical specifications are locked down to form the formal procurement inquiry basis documents, reducing cost and delivery changes caused by later engineering changes.
III. Technical Clarification and Inquiry Document Preparation Stage
After the requirements review is completed, the process enters the technical clarification and inquiry document preparation phase.The Request for Quotation (RFQ) is the formal basis for procurement bidding and price comparison; the piping and fittings RFQ document consists of a commercial part and a technical part.Commercial content includes delivery location, delivery cycle, payment terms, warranty period, liability for breach of contract, and packaging and transportation requirements;The technical part includes drawings, pipe fitting lists, applicable standards, material requirements, inspection and test plan (ITP), quality certificate requirements, marking and traceability requirements, and technical deviation response table.
Technical clarification is divided into internal clarification and external clarification for potential suppliers.Internal clarification is a multi-party joint review of technical terms by procurement, design, construction, and quality departments to unify inspection, packaging, and documentation requirements.External clarification refers to suppliers raising questions after studying the inquiry documents; the procurement team organizes technical personnel to provide unified answers, and all answers are compiled into written clarification minutes as supplementary documents to the inquiry documents and sent to all suppliers participating in the quotation, ensuring that all suppliers quote on a unified technical basis and avoiding distorted price comparisons caused by different suppliers quoting based on different interpretations.
Inquiries for pipeline fittings must be accompanied by drawings and single-line diagrams, clearly define material traceability rules, and specify heat number marking and steel stamp identification requirements.For pressure pipeline fittings, the inquiry documents must clearly specify supplier qualification requirements; suppliers of special equipment fittings must hold the corresponding special equipment manufacturing license, with the licensed scope covering the fitting types, materials, and pressure ratings procured this time.The inquiry documents also require suppliers to submit qualification documents, performance records of similar projects, sources of raw material billets, and inspection plans together with their quotations.
After the inquiry document is prepared and approved, inquiry invitations are sent to the shortlist of qualified suppliers.For regular orders, generally three or more qualified suppliers are selected for price comparison to ensure sufficient competition.
IV. Supplier Qualification Assessment and Quotation Review Stage
Supplier admission assessment is the front-line barrier for risk prevention and control in pipeline fitting procurement; small workshops without qualifications must not be selected for special equipment fittings.Supplier assessment dimensions are divided into six major sections: qualification review, production capacity, inspection and testing capability, track record, quality system, and financial performance capability.Qualification verification focuses on reviewing the special equipment manufacturing license and ISO9001 quality system certificate; for ASME products, the U stamp qualification can be verified;Verify raw material procurement channels and confirm the ability to obtain steel mill quality assurance certificates;Review the factory's non-destructive testing personnel qualifications, heat treatment equipment, and spectral PMI testing equipment.In terms of performance, focus on reviewing supply cases of similar pressure pipeline fittings for oil and gas, chemical, and power station applications, verify past owner evaluations, and check quality complaint records.
Supplier evaluation is divided into admission-stage review and single-order review. New suppliers require on-site factory inspections to verify production lines, physical and chemical laboratories, and warehouse labeling management;For qualified suppliers already in the database, routine orders may use a document review method, while major orders still require factory audits.
After receiving quotation documents from each supplier, technical review and commercial review are conducted separately.Technical review takes priority. Pipeline technical engineers review the technical deviation table, verify whether the supplier has fully responded to drawing, standard, inspection, and certificate requirements, and identify major technical deviations.For example, if a supplier proposes material substitution, reduction of non-destructive testing proportions, or downgrading of certificate levels, these are all major deviations that require key evaluation to decide whether to accept. Material substitution must undergo written design approval, and suppliers are strictly prohibited from substituting materials without authorization.Quotations from suppliers that fail technical review are directly excluded and do not enter commercial price comparison.
Technically qualified quotations enter commercial review, comparing unit price, total price, delivery cycle, payment terms, warranty, and transportation costs.Awarding the bid solely based on the lowest price is not acceptable; full lifecycle risks must be comprehensively evaluated.After the review is completed, a review report is formed, the recommended winning supplier is proposed, and approval is carried out level by level in accordance with the enterprise procurement approval process.After the approval is completed, a notice of award is issued to the selected supplier.
V. Procurement Contract and Technical Agreement Signing Stage
After the supplier is determined, contract negotiations are carried out, and the procurement contract and supporting technical agreement are signed.For pipeline and pipe fitting procurement, the technical agreement has the same legal effect as the contract and is the core basis for subsequent production, inspection, acceptance, and quality dispute determination, and cannot be omitted.
The procurement commercial contract stipulates the scope of supply, total contract price, delivery milestones, payment milestones, transportation responsibilities, warranty period, liquidated damages for breach of contract, and dispute resolution methods.The technical agreement solidifies all technical requirements in detail: pipe fitting specification list, applicable standards, material grades, raw material billet requirements, heat treatment process, non-destructive testing scope and acceptance level, physical and chemical test items, product steel stamp markings, MTC content of quality certification documents, packaging marks, supervision witness points, acceptance criteria, and material substitution approval process.The technical agreement requires joint review and signature by the purchaser's technical and quality personnel.
Contracts and technical agreements need to focus on locking down change clauses, stipulating pricing rules for later drawing modifications and specification additions, to avoid disputes arising from engineering changes.For pressure piping fittings procurement, warranty responsibilities must be clearly specified in the agreement: during the warranty period, if quality issues arise from material or manufacturing defects, the supplier shall bear responsibility for repair, replacement, and compensation for on-site losses.Once the contract text review is completed, both parties affix their seals for it to take effect, the order is officially placed, and the supplier begins production preparation.
VI. Order Production Tracking and Manufacturing Process Supervision Stage
After the contract takes effect, the supplier schedules production according to the delivery plan, and the procurement personnel establish an order tracking ledger to track the progress of all processes including raw material procurement, cutting, forging/forming, heat treatment, machining, and non-destructive testing, regularly collecting production progress photos and records, and giving early warning of delay risks.For routine orders, document-based tracking may be adopted; for important pressure fittings, resident factory or third-party TPI supervision shall be added.
At the raw material incoming stage, the supplier must submit the steel mill quality certificate for raw materials, verify the heat number, and conduct spectral PMI re-inspection when necessary to confirm the material meets requirements; unqualified billets are prohibited from being put into production.After the forging, pushing, and welding forming processes are completed, heat treatment shall be carried out in accordance with the specifications to eliminate residual stress. Heat treatment records and curves must be fully retained and incorporated into the final documentation package.
Supervision work shall set hold points (H points) and witness points (W points) in accordance with the ITP inspection and test plan. For key processes, the purchaser or third-party supervision personnel must be notified in advance to be present for witnessing. Without witness confirmation, the next process shall not proceed.Common witness points: raw material re-inspection, heat treatment, 100% non-destructive testing, dimensional sampling inspection, finished product appearance inspection.Supervision personnel shall verify the product steel stamp and heat number markings to ensure full traceability of markings throughout the process, achieving one-to-one correspondence among pipe fittings, heat numbers, and material certificates, and eliminating material mixing.
During the production tracking stage, the procurement specialist shall regularly organize weekly meetings between the supplier and the purchaser to synchronize progress, identify production delay risks, coordinate in advance to resolve issues with equipment, raw materials, and inspection resources, and ensure on-time delivery.If manufacturing defects occur, rework, repair, or scrapping shall be carried out in accordance with the nonconforming product disposal procedure. After rework, re-inspection is mandatory.
VII. Factory Inspection, Documentation Review, and Packaging and Shipping Stage
After all manufacturing processes of the pipe fittings are completed, the factory inspection stage begins. The supplier's quality inspection department shall carry out finished product inspection in accordance with the technical agreement, drawings, and standards, including appearance inspection, dimensional measurement, thickness testing, spectral re-inspection, non-destructive testing, hardness/impact and other physical and chemical tests, and issue a full set of quality certification documents MTC.
Before delivery, the purchaser's supervisory personnel conduct a pre-delivery release review, checking the physical identification, inspection reports, and heat-number traceability chain, and reviewing the completeness of the full set of documentation.The quality certification documents must include raw material warranty certificates, heat treatment records, NDT non-destructive reports, dimensional records, and product certificates of conformity.If the documentation is incomplete, the data is contradictory, or the steel stamp does not match the heat number on the certificate, release from the factory shall not be permitted.
Products that pass inspection shall be protectively packaged in accordance with the requirements of the technical agreement.Bevels of carbon steel pipe fittings shall be protected, and stainless steel pipe fittings shall be fitted with isolation gaskets to prevent iron ion contamination;Heavy-duty flanges and large-diameter pipe fittings shall use fumigation-free wooden pallets, be stencil-sprayed with shipping marks, and be labeled with the project name, order number, specification, and heat number.The packaging scheme must take into account both the need to prevent impact damage during long-distance transportation and the need for rust prevention.After packaging is completed, arrange loading, handle transportation formalities; after shipment, the supplier shall provide a shipping list and waybill, the purchaser shall update the order ledger, and simultaneously notify the on-site receiving personnel to prepare for receiving the goods.
VIII. On-site arrival receipt and warehousing acceptance stage
The goods arrive at the project site warehouse, and the arrival acceptance process is initiated. Acceptance is divided into document acceptance and physical acceptance.First, check the arrival packing list, shipping list, and quality certificates, and verify the quantity, specifications, and heat numbers;Open the packages for physical inspection of appearance, check the product steel stamp markings, and perform sampling inspection of external dimensions and wall thickness; for high-pressure and GC-class pressure piping fittings, conduct on-site spectral re-verification of materials when necessary.
Acceptance is carried out according to inspection batches, with the same heat number and same specification forming one inspection batch.Check the fitting surfaces for cracks, pores, sand holes, and impact damage, as well as the protection condition of flange sealing faces.Keep records during the acceptance process and take physical photographs.Acceptance results are divided into three categories: qualified, unqualified, and pending determination.Shortage in quantity, incorrect specifications, material mismatch, appearance defects, and missing documentation shall all be judged as nonconforming.Nonconforming products shall be stored in isolation with tag identification, prohibited from being put into construction, and a nonconformity notice shall be issued to the supplier; repair, replacement, or return shall be negotiated, and a closed-loop handling record shall be formed.
Accepted pipes and fittings shall undergo warehousing procedures and be stored by zone, with carbon steel and stainless steel stored separately to prevent mixing; inventory ledgers shall be maintained, heat numbers recorded, and identification kept intact until requisition and installation.Warehousing documents shall be simultaneously transferred to archives management as completion filing documents for pressure piping special equipment.
IX. Document Archiving, Settlement Payment, and Supplier Performance Evaluation Stage
After the goods pass acceptance and all documents have been transferred and archived, the contract settlement process shall be initiated.The supplier shall submit invoices, arrival acceptance sheets, and a complete quality document package; the procurement, finance, and quality departments shall review them, verify contract performance, and pay for the goods according to the milestones agreed in the contract.
All procurement process documents shall be uniformly archived, including procurement applications, inquiry documents, quotations, evaluation reports, contracts, technical agreements, clarification minutes, supervision records, inspection reports, arrival acceptance records, nonconformity handling records, and quality assurance documents.Pressure piping fitting documentation must be archived for long-term preservation to meet special equipment filing and project completion documentation requirements.
After project delivery is completed, a post-performance evaluation of suppliers is carried out, scoring and rating them across five dimensions: product quality, on-time delivery rate, documentation completeness, technical responsiveness, and after-sales service. The evaluation results are incorporated into supplier directory management.Suppliers with excellent performance evaluations may be given priority for inquiries in subsequent regular orders;Suppliers with major quality issues, multiple delays, or severely incomplete documentation shall be downgraded or removed from the qualified supplier directory.
X. Typical Risks and Control Measures in the Regular Procurement Process
Multiple potential risks exist throughout the entire regular order procurement process for piping fittings, and a risk identification mechanism needs to be established.First, risks at the demand stage: incomplete drawing parameters and inconsistent quantities in single-line diagram material tables cause omissions and errors in supply items.Countermeasure: Establish a dual technical review system; procurement requirements must be reviewed for parameters by piping discipline engineers.Second, supplier qualification risk: selecting manufacturers without special equipment licenses.Countermeasure: strictly implement supplier admission, conduct dynamic annual qualification reviews, and regularly verify the validity of licenses.Third, technical deviation risk: suppliers privately substitute materials and lower inspection levels.Countermeasure: the technical agreement clearly stipulates that material substitution must undergo written design approval, and materials are verified during the supervision and manufacturing stage.Fourth, documentation risk: quality certificates do not match the actual heat numbers, and certificates are missing.Countermeasure: pre-review the full set of documents before delivery; if the documents are non-compliant, release is not permitted.Fifth, delivery delay risk: rising raw material prices and tight factory production scheduling lead to delays.Countermeasure: dynamically track the order ledger, set warning milestones, and lock in billets in advance for long-lead-time materials.Sixth, there is a risk of mixed materials during arrival inspection and acceptance, with pipe fittings of different materials packed together and steel stamps blurred.Countermeasure: conduct on-site unpacking and verification of steel stamps, and add on-site spectral spot checks for important materials.
Although routine orders are lower in technical complexity than large special projects, they involve large batches and high frequency, and the accumulation of risks will continuously affect project quality. The procurement department must not simplify the process and must adhere to technology first, with technical review taking priority over commercial price comparison.
XI. Conclusion
Procurement of routine orders for pipes and pipe fittings is a fully closed-loop standardized management process from demand submission to supplier post-evaluation. Unlike ordinary commodity procurement, the special equipment attribute of pressure piping determines that procurement activities must take technical compliance, material traceability, and complete inspection documentation as the core mainline.The entire procurement process is divided into nine major stages: demand review, technical clarification and inquiry, supplier evaluation and quotation review, contract and technical agreement signing, production supervision, factory inspection, packaging and shipping, on-site acceptance, documentation settlement, and performance evaluation.Each stage is provided with review control points, focusing on controlling drawing parameters, supplier qualifications, material traceability, inspection and testing, and quality certification documents, so as to prevent procurement risks such as wrong items, missing items, material nonconformity, and missing documentation.
In EPC, petrochemical, oil and gas, and power station engineering practice, many procurement quality accidents originate from simplified procurement processes that emphasize price while neglecting technical control.Establish a standardized routine order procurement process for pipeline fittings, implement technical review and supervision, inspection and acceptance requirements at each stage, stabilize the supply quality of fittings, reduce on-site rework, ensure the smooth acceptance of pressure pipeline projects, and reduce safety hazards of special equipment.Procurement management is not simply price comparison and order placement, but systematic work coordinated across technical, commercial, and quality functions.Enterprises should continuously improve procurement management systems, strengthen the professional capabilities of procurement, technical, and supervision personnel, and continuously optimize procurement processes, so as to achieve controllable risks throughout the entire life cycle of pipeline fitting procurement and ensure stable and reliable material supply for engineering projects.
References
[1] TSG 31-2025, Safety Technical Regulation for Industrial Pipelines [S]. State Administration for Market Regulation, 2025.
[2] GB/T 20801, Pressure Piping Code — Industrial Piping [S].
[3] GB/T12459-2017, Steel Butt-Welding Seamless Pipe Fittings [S].
[4] Li Xuedao. Practice of Procurement and Supervision of Pressure Piping Components [M]. Beijing: China Machine Press, 2023.
[5] Hou Wei. Research on Material Procurement Management for Overseas EPC Engineering Projects [D]. University of International Business and Economics, 2017.
[6] Chen Jing. Research on Quality Control of Pipeline Material Procurement in Petrochemical Engineering Projects [J]. Engineering Management, 2024.
