I. Introduction
In international EPC engineering projects such as global oil and gas, chemical, power station, municipal water supply and drainage, and offshore platform projects, pressure rating is a core technical indicator for pipeline and pipe fitting selection, technical agreement signing, product manufacturing, inspection and acceptance, and directly determines the pressure-bearing safety of the piping system and project compliance.Two major pressure rating systems coexist in foreign trade markets: the Class pound rating system based on ASME standards, widely used in oil and gas petrochemical projects in North America, the Middle East, and Southeast Asia;and the PN nominal pressure system based on EN, DIN, and ISO, mainly used in the EU, European infrastructure, and some Asia-Pacific municipal projects.The domestic national standard GB/T1048 also includes both PN and Class series, providing a basic specification for aligning domestic and foreign trade projects.
In foreign trade practice, a large number of quality disputes, owner rejections, and supervisory rejections are often rooted in procurement personnel's misunderstanding of the two pressure rating systems, using only rough numerical values for conversion, simply equating Class150 with PN16 and Class300 with PN40, and ignoring the pressure derating effect caused by temperature and material group.For pipe fittings of the same pound rating, there are obvious differences in allowable service pressure under different materials and different working temperatures;The PN system uses 20°C normal temperature as the baseline, and as temperature rises, the allowable pressure-bearing capacity of pipe fittings also decreases. The temperature-pressure decay curves of the two do not coincide, and they cannot be directly interchanged.
Pipe fittings come in a wide variety of categories; flanges, seamless butt-welded fittings, forged socket-welded fittings, and steel plate rolled and welded fittings each follow different standards, and there are differences in the applicable range of pressure ratings and in the logic of wall thickness calculation.Flange pressure ratings are governed by ASME B16.5 and EN1092-1;seamless butt-welded fittings are governed by ASME B16.9;forged socket-welded and threaded fittings are governed by ASME B16.11;European-standard butt-welded fittings are governed by EN10253.Foreign trade orders must not only ensure the pressure rating of the fitting body, but also ensure that the pressure ratings of the complete set of components—flanges, fittings, valves, gaskets, and bolts—are consistent; a mismatch in the pressure ratings of the complete set of pressure-bearing components will cause sealing failure of the piping system and lead to leakage safety accidents.
As domestic foreign trade business in pipeline fittings continues to expand, domestically produced fittings are exported in large quantities to countries around the world, and owners, consulting companies, and third-party inspection agencies in different countries are imposing increasingly strict requirements on pressure rating documentation, temperature-pressure curve certification, and material group verification.This article systematically explains the connotations of the two major pressure rating systems for pipeline fittings in foreign trade export, compares the underlying design logic of the two systems, distinguishes the methods for determining pressure ratings for different categories of fittings, summarizes pressure rating selection principles and key points of technical agreement clauses, analyzes high-frequency misunderstandings in foreign trade business, and establishes a full-process risk control system for pressure ratings, so as to provide complete technical support for bidding, procurement, production, inspection, and delivery in the pipeline fittings foreign trade business.
II. Basic Definitions of the Two Major International Systems for Pressure Ratings of Pipes and Fittings
2.1 ASME Class Pound-Rating System (American Standard System)
The Class pound-rating system originates from the ASME B16.5 flange standard and is widely used in conjunction with the ASME B31 series pressure piping codes; it is the most commonly used pressure rating designation in oil and gas, petrochemical, and international EPC projects.Many procurement personnel have a cognitive misconception, believing that Class150 represents a pressure of 150 psi, which is a typical misunderstanding.Class is a dimensionless rating code and does not directly represent a fixed pressure value; its allowable working pressure is jointly determined by the material group and the working temperature, and the actual allowable pressure-bearing value is obtained by looking it up in the standard pressure-temperature rating table (P-T table).
Commonly used Class ratings include Class150, Class300, Class400, Class600, Class900, Class1500, and Class2500.At a normal temperature of 38°C, the allowable pressure of A105 carbon steel Class150 flanges is approximately 19.6 bar, Class300 approximately 48.3 bar, and Class600 approximately 102 bar;when the medium temperature rises, the material strength decreases, and the allowable pressure-bearing capacity of fittings of the same rating decreases accordingly; the higher the temperature, the greater the pressure derating amplitude.For example, under high-temperature conditions, a Class 150 carbon steel flange will have a significantly lower allowable pressure rating than its room-temperature rating. This is the most core feature of the pound-class system: the class remains unchanged, but as temperature changes, the allowable pressure rating changes accordingly.
Different pipe fitting categories have different boundaries for pound-class standards: ASME B16.5 is used for NPS1/2 to NPS24 flanges;ASME B16.9 covers factory-manufactured seamless butt-welded elbows, tees, reducers, and caps, matching flange pound classes;ASME B16.11 is used for NPS1/8 to NPS4 forged socket-weld and threaded pipe fittings. The pound classes include Class2000, Class3000, Class6000, and Class9000 high-pressure forgings, specifically for small-diameter high-pressure instrument piping and sampling lines.MSS SP-25 standardizes the stamped marking of pipe fittings. The product body must be stamped with the Class rating, material, heat number, and standard number to meet overseas third-party inspection identification and traceability requirements.
2.2 PN nominal pressure system (European standard/national standard metric system)
The PN nominal pressure system implements EN1092-1, DIN, ISO7268, and GB/T1048. The number after PN represents the maximum allowable working pressure of the pipe fitting at 20°C, in bar.PN16 means a maximum pressure rating of 16 bar at 20°C, PN25 is 25 bar, and PN40, PN63, and PN100 increase sequentially. It is suitable for municipal water supply and drainage, heating, general chemical engineering, and EU regional engineering projects.
The PN system also has temperature derating rules, except that the reference temperature is fixed at 20°C. When the pipeline medium temperature is higher than 20°C, the material yield strength decreases, and the allowable service pressure of the fitting is lower than the nominal PN value.The European standard EN10253 for butt-welded fittings and EN1092 flanges both use PN classification.The advantage of the PN system is that it is intuitive and easy to understand under normal-temperature conditions, making it suitable for normal-temperature low-pressure utility pipelines;the disadvantage is that pressure derating calculations under high-temperature conditions are cumbersome, and parameter conflicts are likely to arise when interfacing with American-standard project drawings.
GB/T1048 "Definition and Selection of Nominal Pressure for Pipeline Components" includes both the PN and Class series and clearly states that the two can only be used as approximate references and are not unconditionally interchangeable. When domestic enterprises undertake conversion projects for domestic and foreign trade, this standard must be used as the technical basis, and simple numerical substitution must not be made directly.
2.3 Approximate Correspondence Between Class and PN and Boundary Limitations
There is a rough comparison table in the industry: Class150 approximately corresponds to PN20, Class300 approximately to PN50, Class600 approximately to PN100, and Class900 approximately to PN150.This comparison table is only for reference in preliminary bidding estimates and must strictly not be used directly for drawing conversion, signing of technical agreements, or product manufacturing.
Approximate equivalence holds only under normal temperature and specific carbon steel material group conditions;once the temperature rises or the material is changed to stainless steel or alloy material, the temperature-pressure curves of the two systems no longer match, and the approximate conversion becomes invalid.For example, under high-temperature working conditions, with the same Class150 and PN20, the allowable pressure-bearing difference between the two is obvious; direct replacement in supply will cause the entire pipeline to have insufficient pressure-bearing capacity, posing a major safety hazard.Foreign trade personnel must keep firmly in mind: the two systems belong to different design systems, and there is no universal unconditional equivalent replacement; project selection shall be based on the standards and P-T temperature-pressure tables specified in the drawings, and must not rely on empirical conversion.
III. Pressure Rating Determination and Matching Rules for Different Types of Pipeline Fittings
For foreign trade export orders, pipe fittings, flanges, valves, gaskets, and bolts must all have a unified pressure rating across the entire set; if a single component has a lower pressure rating, the pressure-bearing upper limit of the entire system is determined by the lowest-rated component. This is the basic principle of pipeline system selection.
3.1 Flange Pressure Rating
Flanges are the benchmark components for the pressure rating of the entire pipeline; American standard flanges ASME B16.5 are classified by Class, and European standard EN1092-1 is classified by PN.The flange pressure rating also determines the sealing face dimensions, bolt hole diameter, number of bolts, and flange thickness.Flanges of different ratings cannot be mated and assembled; for example, the bolt hole circle diameters of Class 150 flanges and Class 300 flanges are inconsistent, making paired installation impossible, and even with the same nominal size, they cannot be mixed.The most common mistake in foreign trade projects: the customer only confirms the nominal size and ignores the flange pound rating, so the goods cannot be mated upon arrival at the port, resulting in huge rework losses.
3.2 Seamless butt-welded pipe fittings (elbows, tees, reducers, pipe caps)
ASME B16.9 butt-welded fittings are not directly marked with a Class rating; instead, they match the pressure-temperature ratings of the corresponding Class flanges through the wall thickness SCH series and material.SCH wall thicknesses include SCH40, SCH80, SCH160, etc.; the larger the SCH value, the thicker the wall thickness and the higher the pressure-bearing capacity.Many procurement personnel confuse the concepts of SCH wall thickness and Class pound rating; SCH represents wall thickness, while Class represents the pressure rating of the entire system, and the two are related but are not the same parameter.In foreign trade orders, the wall thickness selection of butt-welded fittings must meet the pressure-bearing requirements of the flange Class rating at the design temperature; the pressure rating cannot be determined directly based solely on the SCH number.
3.3 Forged socket weld and threaded pipe fittings
ASME B16.11 forged pipe fittings are directly marked with Class ratings, Class 3000, Class 6000, and Class 9000; the forging body is integrally forged with no base metal weld seams, and they are widely used in small-diameter high-pressure instrument piping.The pressure class of forged pipe fittings is independent, and they need to be matched with forged flanges of the same class; the pressure rating must be consistent with that of the main pipe system.For pressure rating verification of forgings, in addition to the strength of the body itself, UT/MT/PT non-destructive testing of the matching forgings is also required to meet the project's forging level requirements.
3.4 Steel plate rolled and welded pipe fittings
Both GB/T13401 and ASME B16.9 allow rolled and welded pipe fittings; the pressure rating of welded pipe fittings depends not only on the plate thickness but also on welding quality, post-weld heat treatment, and the results of weld seam non-destructive testing.The weld seam is the weak link; under the same wall thickness conditions, the pressure rating safety margin of welded pipe fittings is lower than that of seamless pushed pipe fittings.PN-rated welded pipe fittings are commonly used in foreign trade low-pressure municipal projects;For high-pressure process pipelines, rolled welded fittings are generally not recommended.
3.5 Matching pressure ratings for gaskets and bolts
Foreign trade projects often overlook the pressure rating matching of gaskets and bolts.For flanges of the same Class, gaskets and bolt materials of the corresponding grade must be selected.Under high-temperature and high-pressure conditions, the strength of bolt materials decreases with temperature; if the bolt pressure rating is insufficient, leakage will occur at the flange seal.The entire set of pressure-containing components must have unified material group and pressure-temperature ratings, and the technical agreement must explicitly include the matching grades of bolts and gaskets.
IV. Basic principles for pressure rating selection in foreign trade exports
4.1 Prioritize compliance with project drawings and the owner's technical specifications
First principle of selection for foreign trade projects: strictly follow the standards and pressure ratings specified in the P&ID drawings and the owner's technical specifications. If the drawings clearly specify an ASME project, select a full set of components with Class ratings;if an EU project specifies EN standards, use PN nominal pressure.If the drawing specifies Class, you must not substitute PN products on your own;if the drawing specifies PN, you must not substitute Class-rated products. Arbitrarily substituting the pressure system during the bidding stage will directly result in rejection of the technical bid.
4.2 Check the pressure-temperature P-T tables according to design temperature and medium, and perform derating verification.
Pressure rating selection cannot rely solely on the normal-temperature rated pressure; you must take the maximum design pressure + maximum design temperature, and within the corresponding standard P-T table, verify the allowable pressure-bearing capacity of the fitting material at that temperature, ensuring that the allowable pressure-bearing capacity ≥ design pressure, while also reserving a safety margin. Generally, for foreign trade EPC projects, the safety factor is 1.2~1.5.Under high-temperature conditions, material strength decreases, so derating calculations must be performed. The normal-temperature nominal pressure must not be used as the basis for selection. This is the most core technical control point in foreign trade high-pressure projects.
4.3 Additional verification for working conditions such as medium corrosion, fatigue, and hydrogen embrittlement
The medium affects the allowable stress of the material, indirectly changing the applicable boundary of the pressure rating.For wet hydrogen sulfide sour oil and gas, seawater chloride ion corrosion, hydrogen medium, and alternating fatigue load conditions, even if the pressure rating value is sufficient, additional verification of the material's corrosion resistance is required, such as the NACE MR0175 sour service requirement.At the same pressure rating, different materials have different corrosion resistance. Corrosion thinning will reduce the actual pressure-bearing capacity of pipe fittings, so a corrosion allowance must be reserved during selection.
4.4 The pressure ratings of the entire set of components must match, with no weak link like the shortest stave of a barrel
Pipe fittings, flanges, valves, gaskets, and bolts must have unified pressure ratings and material groups. The pressure ratings of the entire set of pressure-bearing components are not allowed to be mixed high and low.For example, a Class300 flange cannot be paired with a Class150 gasket. The gasket has insufficient pressure-bearing capacity and will become the weak point of the system, causing leakage accidents.When preparing foreign trade quotations, material requisitions, and procurement lists, pressure ratings must be checked as a complete set, and it is not acceptable to check only the pipe fitting body alone.
4.5 Export certification matching pressure rating
For CE certification of pressure equipment under the EU PED for export, the product pressure rating is a core parameter of the certification scope, and the pressure rating of the supplied product must be within the range covered by the certificate;For Middle East SABER and Saudi PVoC certification, the pressure rating marked on the product nameplate and MTC material certificate must be consistent with the order.If the pressure rating of the supplied product exceeds the scope covered by the certificate, the goods will be blocked during customs clearance at the destination port and cannot pass local special equipment filing.
V. Key control points for pressure ratings in foreign trade orders in technical agreements, documentation, and steel stamps
5.1 Lock pressure rating clauses in the technical agreement and eliminate vague descriptions
The foreign trade technical agreement must clearly state: the applicable standard, pressure rating (Class or PN), material grade, material group, design temperature, and design pressure, and clearly specify that the pressure-temperature ratings are based on the standard P-T table.It is prohibited to simply write vague equivalent descriptions such as "Class150≈PN16".The agreement states: it is not permitted to substitute materials across pressure ratings without the owner's written approval;Any material substitution or rating downgrade must go through the written approval process.For butt-welded pipe fittings, in addition to the pressure rating, the SCH wall thickness and corrosion allowance shall also be agreed upon;For forged pipe fittings, the forging grade and non-destructive testing requirements shall be specified.
5.2 Product steel stamping and nameplate marking of pressure rating
For export pipe fittings and flanges, the steel stamping on the body must clearly indicate the pressure rating, standard number, material, and heat number.Products under American standards shall be marked with the Class rating, products under European standards shall be marked with the PN rating, and MSS SP-25 specifies the steel stamping content.Overseas supervision personnel conduct on-site inspection and verify first and foremost whether the stamped rating matches the order and drawings;Missing steel stamps or incorrect grade markings will directly result in the product being judged as non-conforming.
5.3 Material Test Certificate (MTC) includes proof of pressure-temperature ratings
For export MTC material certificates (EN10204 3.1 or 3.2), in addition to chemical composition and mechanical properties, the material group and P-T pressure-temperature table reference must be attached to prove that the material meets the pressure rating requirements at the project design temperature.High-end EPC projects require third-party witnessed 3.2 certificates; the pressure rating information in the certificate must be fully consistent with the product steel stamps and technical agreement, and any data contradiction will lead to rejection by the owner.
5.4 Supervision and pre-shipment inspection verify pressure ratings
For high-value foreign trade orders, third-party supervision will check wall thickness, dimensions, and material mechanical properties, and reversely verify whether the product meets the corresponding pressure rating.If butt-welded pipe fittings have insufficient wall thickness, even if marked with a Class rating, the actual pressure-bearing capacity cannot meet the standard requirements, which constitutes downgraded supply.Before shipment, the full set of English documentation must be pre-reviewed to confirm that pressure rating parameters are consistent, and then packing and shipping can be arranged, avoiding discrepancies between documents and actual goods after arrival at the port.
VI. Analysis of High-Frequency Misconceptions About Pressure Ratings of Foreign Trade Export Pipes and Fittings
Misconception 1: Directly converting Class and PN by numerical value, believing that Class 150 equals PN16, and directly substituting for supply under high-temperature conditions.Approximate reference at room temperature is not equivalent interchangeability; the allowable pressure decay curves differ at high temperatures, which can easily cause insufficient pressure-bearing capacity.
Misconception 2: Confusing SCH wall thickness with Class pound rating, believing that SCH80 equals Class 300.SCH is a wall thickness series, while Class is the pressure rating of the entire system; the two are related but cannot be directly equated, and the allowable pressure differs for the same SCH wall thickness with different materials.
Misconception 3: Only checking the pressure rating of pipe fittings while ignoring the matching ratings of flanges, gaskets, and bolts, resulting in mismatched component ratings and sealing leakage after the pipeline is put into operation.
Misconception 4: Selecting models based only on room-temperature pressure without performing high-temperature derating verification; material strength decreases under high-temperature conditions, and the actual pressure-bearing capacity cannot meet design requirements.
Misconception 5: The drawings specify an ASME Class project, but PN European-standard pipe fittings are purchased during procurement, believing they can be used as long as the nominal size is the same; the flange bolt holes do not match, making on-site installation impossible.
Misconception 6: The pressure rating on the product certificate, the stamped rating, and the parameters in the order technical agreement are inconsistent, and the documents conflict; overseas third-party supervision directly rejects the entire batch of goods, resulting in port demurrage and return shipment losses.
Misconception 7: For welded pipe fittings, the pressure rating is determined solely by the plate thickness, ignoring weld seam inspection and heat treatment; weld defects cause the actual pressure-bearing capacity to fall short of the nominal rating.
VII. Pressure Rating Selection Habits and Business Strategies in Different Regions of the Foreign Trade Market
Oil and gas, petrochemical, LNG, and hydrogenation EPC projects in North America, the Middle East, Central Asia, and Southeast Asia generally adopt ASME B31.3 process piping and the Class pound rating system, with flange Class150/300/600/900, matched with ASME B16.9 butt-welded pipe fittings and ASME B16.11 forged pipe fittings, requiring 3.2 material certificates, third-party supervision, and PED or SABER certification.
EU, local European projects, and African municipal water supply and heating projects mostly adopt the EN/PN system, with EN1092 flanges and EN10253 pipe fittings, mainly PN10, PN16, PN25, and PN40, requiring PED CE pressure equipment certification, with emphasis on normal-temperature low-pressure utility pipelines.
For domestic export-related EPC general contracting projects, there are mixed standards in drawings, with some drawings marking both ASME and EN parameters at the same time; this is the highest technical risk scenario in foreign trade, and a separate technical review must be conducted to clarify which standard is used as the acceptance benchmark, and mixing the two standards is prohibited.
Regarding the business strategy of foreign trade enterprises, enterprises should establish a pressure rating review process in the early stage of order acceptance; technical personnel verify the medium, temperature, pressure, and standard system in the drawings, determine whether to use Class or PN, and verify the matching of the entire set of components;Improve Chinese-English technical templates and fix pressure rating and temperature-pressure verification clauses in the technical agreement;Establish a supplier control mechanism to verify whether the factory's production, inspection, and certification systems can meet the requirements for products of the corresponding pressure class;For high-value orders, set up pre-review of factory documentation to identify issues such as inconsistent classes, certificates, and steel stamps in advance, reducing cross-border performance risks.Enterprises need to upgrade from pure product sales to pressure-class supporting technical services, providing overseas general contractors with complete pressure matching solutions for pipeline components to enhance project bidding competitiveness.
VIII. Conclusion
Foreign trade export pipeline fittings involve two independent pressure class systems: ASME Class pound ratings and EN PN nominal pressure. The two have different design bases and temperature-pressure derating logic, and can only be approximately compared at room temperature; they cannot be unconditionally interchanged as equivalents.Pressure class is not a single parameter; it is a complete pressure-bearing system composed jointly of material, temperature, wall thickness, structural form, welding quality, and matching flanges, gaskets, and bolts.
Throughout the entire process of foreign trade procurement, bidding, manufacturing, and delivery, project drawings and owner technical specifications must be taken as the primary basis; the pressure class determination rules for flanges, seamless butt-welded fittings, forged fittings, and rolled welded fittings must be distinguished; and pressure derating verification at design temperature must be completed to ensure that the pressure class of the entire set of pressure-bearing components is consistent.The pressure class parameters in technical agreements, product steel stamps, MTC material certificates, and supervision documents must remain fully consistent, eliminating arbitrary substitution across systems and supply at reduced class.
Foreign trade operations need to avoid typical pitfalls such as simple numerical conversion, confusion between SCH and Class concepts, ignoring the grade of matching components, and the lack of high-temperature derating calculations, and establish a technical review mechanism for pressure ratings in the early stage of orders, while improving export certification, pre-review of documents, and factory inspection control.For foreign trade enterprises of domestic pipeline and fittings, accurately mastering the international pressure rating system and standardizing pressure rating selection and document delivery can significantly reduce the risk of rejection and claims in overseas projects, and continuously enhance the competitiveness of domestic pipeline and fittings in the supply chain of global EPC engineering projects.
References
[1] GB/T1048-2019, Definition and selection of nominal pressure for pipeline components [S]. State Administration for Market Regulation.
[2] ASME B16.5, Pipe flanges and flanged fittings [S]. American Society of Mechanical Engineers.
[3] ASME B16.9, Factory-made wrought butt welding fittings [S]. American Society of Mechanical Engineers.
[4] ASME B16.11, Forged fittings, socket-welding and threaded [S]. American Society of Mechanical Engineers.
[5] ASME B31.3, Process piping code [S]. American Society of Mechanical Engineers.
[6] EN 1092-1, Flanges and their joints - Circular flanges for pipes [S]. European Committee for Standardization.
[7] EN 10253, Butt-welding pipe fittings [S]. European Committee for Standardization.
[8] MSS SP-25, Standard Marking System for Valves, Fittings, Flanges [S]. Manufacturers Standardization Society.
[9] TSG31-2025, Safety Technical Regulation for Industrial Piping [S]. Special Equipment Bureau of the State Administration for Market Regulation.
[10] GB/T 20801, Pressure Piping Code - Industrial Piping [S]. National Technical Committee for Standardization of Pressure Piping.
[11] PED 2014/68/EU, Pressure Equipment Directive of the European Union [S]. European Commission.
[12] ISO7268, Pipe components - Definition of PN and Class [S]. International Organization for Standardization.
[13] ASTM A105/A105M, Standard Specification for Carbon Steel Forgings for High-Temperature Service [S]. American Society for Testing and Materials.
[14] Li Xuedao. Practical Guide to Foreign Trade Procurement and Quality Control of Pressure Piping Components [M]. Beijing: China Machine Press, 2023.
[15] China Customs Brokers Association. Practical Guide to Import and Export Compliance for Steel Products [M]. Beijing: China Customs Press, 2024.
